ML2400L LED Binocular Brightfield Biological Microscope

$3,700.00

The Meiji Techno ML2400L LED Binocular Brightfield Biological Laboratory Series is one of our most rugged fully equipped microscope systems from Japan with a Flat-top Mechanical Stage and a forward facing nosepiece.  It offers many high performance features and a stable rectangular base for stability.  High resolution DIN Standard SM Plan objectives offer crisp, clear, high contrast images and are offered as part of the standard package.  A built in integrated Koehler illuminator with a field iris and LED lamp and variable intensity control is provided standard equipment to complement the SM PLAN optics.   A green monitor lamp is lit to indicate that the lamp is on for easy on/off recognition in any laboratory setting. The low voltage, high intensity, pre-centered LED lamp provides high level illumination can be adjusted to maximize the evenness of the bulb illumination. The ML2400L Series also features a specially designed Achromatic N.A. 1.25 condenser with iris diaphragm and filter carrier.   The die cast metal stand has a chemical resistant finish and is the most rugged, durable finish in the market today.  Equipped with low position factory calibrated coaxial coarse and fine focus controls, tension adjustment and a built in stage stop lever to protect the specimen and objectives from accidental damage during use.  The ML2400L Series Laboratory Biological Microscope is a versatile and modular system designed to accept a wide variety of optional accessories and is backed by Meiji Techno’s Limited Lifetime Warranty.

The Meiji Techno ML2400L LED Binocular Brightfield Biological Laboratory Series is one of our most rugged fully equipped microscope systems from Japan with a Flat-top Mechanical Stage and a forward facing nosepiece.  It offers many high performance features and a stable rectangular base for stability.  High resolution DIN Standard SM Plan objectives offer crisp, clear, high contrast images and are offered as part of the standard package.  A built in integrated Koehler illuminator with a field iris and LED lamp and variable intensity control is provided standard equipment to complement the SM PLAN optics.   A green monitor lamp is lit to indicate that the lamp is on for easy on/off recognition in any laboratory setting. The low voltage, high intensity, pre-centered LED lamp provides high level illumination can be adjusted to maximize the evenness of the bulb illumination. The ML2400L Series also features a specially designed Achromatic N.A. 1.25 condenser with iris diaphragm and filter carrier.   The die cast metal stand has a chemical resistant finish and is the most rugged, durable finish in the market today.  Equipped with low position factory calibrated coaxial coarse and fine focus controls, tension adjustment and a built in stage stop lever to protect the specimen and objectives from accidental damage during use.  The ML2400L Series Laboratory Biological Microscope is a versatile and modular system designed to accept a wide variety of optional accessories and is backed by Meiji Techno’s Limited Lifetime Warranty.

Includes:
   • ML2400L: The ML2400L is a LED Brightfield Binocular Laboratory Compound microscope with Koehler LED  illumination with a forward facing quadruple ball bearing nosepiece. High resolution DIN Standard SM Plan objectives offer crisp, clear, high contrast images and are offered as part of the standard package.  A built in integrated Koehler illuminator with a field iris and LED lamp and variable intensity control is provided standard equipment to complement the SM PLAN optics. The low voltage, high intensity, pre-centered LED lamp provides high level illumination can be adjusted to maximize the evenness of the bulb illumination. Flat-Top Mechanical stage with 171mm and 140mm rectangular stage with movement of 78mm (X) x 52mm (Y) with drop down Ergonomically placed low positioned coaxial controls and a detachable specimen guide.
   • MA602: Inclined Binocular head Inclined at 30°, 360° rotatable, dual graduated diopter eyetubes with interpupillary adjustments 52mm to 72mm

   • MA406 qty#2: DIN HWF10X eyepiece, Field No. 18, (each)

   • MA622: 4X/0.10 Planachromat objective
   • MA623: 10X/0.25 Planachromat Objective
   • MA625: 40X/0.65 Planachromat Objective, spring loaded
   • MA627: 100X/1.25  Planachromat Objective, spring loaded

   • MA661: Achromatic substage condenser 1.25 NA with iris diaphragm and 30mm filter tray
   • Stage: Mechanical X-Y stage with attached finger assembly and drop down post, attached stage is 120mm x 140mm rectangular mechanical stage with movements of 75mm (X) x 40mm (Y) and is graduated with Vernier readings to 0.1mm, equipped with low positioned drop down coaxial controls. (Factory Installed)

   • Focusing Adjustment: Coaxial coarse and fine focusing controls with graduation reading 2 microns power division.  Incorporates tension adjustment and safety Auto-focus stage stop lever

   • MA289/05: Blue filter, clear, 29.8mm diameter
   • MA676: Attachable clinical specimen holder for MA596R and MA596L
   • MA596R: Flat-top stage with clinical specimen holder, 78mm X 52mm, X-Y movement, with drop down coaxial controls (right) (left hand available upon request)
   • LED/SP-1: 3W LED, 5500K color temperature
   • MA808/10: AC adapter for ML2000L, ML5000L, ML6100L, ML6500L, and ML9000L series. AC Input: 100V~240V, DC Output: 5V 2.5A
   • MA700: Immersion Oil. 15cc
   • MA701: Dust Cover for ML2000L
   • Manual: Meiji Techno America ML2000L Manual
   • Warranty: Limited Lifetime Warranty Card
